This radar is mainly used for pre-disaster monitoring and the prevention of secondary disasters.By remotely scanning the surface of the monitoring area, the high-precision displacement of the entire area is obtained, and continuous monitoring of the entire area is realized. And through the comparative analysis of the scanning results and threshold, the automatic early warning is realized in order to achieve the purpose of early detection, and warning, guaranteeing safety and reducing losses. The product can work all day, in all-weather conditions, detect large-scale area with high-precision. It is suitable for slope monitoring in open-pit mines, water conservancy and hydropower dams, and geological landslide disasters.
7x24 hours non-contact wide-area remote monitoring
All-day, all-weather, not affected by rain, objects, light and other conditions
No need to construct or install calibration objects on the monitoring surface in advance
Independent 3D terrain mapping
Sound and light integration Alarm and early warning reports are automatically generated
Chinese interactive interface + localized after sales support and service.
| Target type | Bare surface |
| Distance | ≥5km |
| Deformation accuracy | ≤0.1mm |
| Resolution | 0.3m x 4.0mrad@1km |
| Monitoring range（Horizontal） | 90° |
| Monitoring range（Vertical） | 45° |
| Length x width x height | 320cm x 50cm x 50cm |
| Weight | ≤75KG |
| Power requirement | 220V AC |
| Monitoring frequency (data rate) | 1-6min |
| Power consumption | >100W |
| Operating temperature | -40℃~60℃ |
| Protection level | IP66 |
